Specifications
Build Volume
- Build Volume
- 500 × 500 × 1000 mm (250 L)
Machine
- Physical Dimensions
- 750 × 900 × 1500 mm
- Weight
- 75 kg
Motion System
- Kinematics
- IDEX (Independent Dual Extruder)
- Max Toolhead Speed
- 500 mm/s
- Max Acceleration
- 20,000 mm/s²
Toolhead
- Configuration
- Dual nozzle (IDEX)
- Max Hot End Flow
- 32 mm³/s
- Nozzle
- Hardened Steel, 0.4 mm
- Max Nozzle Temperature
- 300 °C
- Filament Diameter
- 1.75 mm
Filament System
- Channels
- 12 (6 per nozzle)
- Runout Sensor
- Per channel
- Spool Size
- Standard 1 kg spools
Chamber
- Temperature Control
- Active
- Humidity Control
- Active
- Max Chamber Temperature
- 65 °C
Heatbed
- Build Plate
- Flexible Steel with PEI Surface
- Max Bed Temperature
- 120 °C
Supported Materials
- Standard
- PLA, PETG, TPU, ABS, ASA, PVA, PET
- Capable
- PA (Nylon), PC, Carbon / Glass Fiber Reinforced
Calibration
- Toolhead Offset
- Automatic
- Bed Leveling
- Automatic
- Vibration Compensation
- Supported
- Flow Compensation
- Supported
Sensors & Detection
- AI Failure Detection
- Supported
- Power Loss Recovery
- Supported
- Filament Runout
- Supported
- Chamber Camera
- 5 MP, live view
- Humidity & Temperature
- Supported
- Door Sensor
- Supported
Electronics & UI
- Touchscreen
- 10 in, 1280 × 800
- Processor
- 4-core Arm Cortex-A76 2.4 GHz
- Connectivity
- Wi-Fi 2.4 GHz, USB, LAN-only mode
- Storage
- Micro SD Card (inbuilt)
- Max Input Power
- 1600 W (200–240 V)
Software
- Slicer
- OrcaSlicer
- Firmware
- Klipper
- Supported OS
- Windows, macOS, Linux
